Ubiquity USW-Flex 46W Compact 5-Port Layer 2 PoE Switch Outdoor-Ready with PoE++ Support, Flexible Desktop/Wall/Pole Mount, 10 Gbps Switching Capacity

Description

• Flexible 5-Port PoE Switch: Equipped with 4 PoE+ ports and 1 PoE++ port supporting 1G/100M/10M Ethernet speeds for diverse device connectivity.
• Robust PoE Budget: Provides up to 46W total PoE power with a maximum of 25W per PoE+ port to power demanding network devices.
• High Switching Performance: 10 Gbps switching capacity, 5 Gbps total non-blocking throughput, and 7 million packets per second forwarding rate ensure reliable traffic handling.
• Advanced Layer 2 Features: Supports egress rate limiting, flow control, port isolation, port mirroring, and jumbo frames for enhanced network control and diagnostics.
• Compact and Versatile Form Factor: Supports desktop, wall, and pole mounting options with a compact size of 122.5 x 107.1 x 28 mm (4.8 x 4.2 x 1.1 inches).
• Outdoor-Ready Design: Operates within an extended temperature range (-40 to 65 C) and 5 to 95% noncondensing humidity, ideal for challenging environments.
• Efficient Power Management: Supports PoE input with a voltage range of 5057V and power consumption of 5W (excluding PoE output) or 51W (including PoE output).
• Enhanced Durability: Includes ESD protection up to 16kV air/contact discharge to safeguard against electrostatic damage.
• Lightweight and Portable: Weighs only 230 grams (8.1 ounces) for easy installation and deployment flexibility.

The USW-Flex 46W is a versatile, compact 5-port Layer 2 PoE switch engineered for both indoor and outdoor deployments. Featuring four PoE+ ports and one PoE++ port, this switch delivers a total PoE budget of 46W, supporting power-hungry devices such as wireless access points and IP cameras with up to 25W per PoE+ port. Its flexible form factor supports desktop placement, wall mounting, or pole installation, making it ideal for a wide range of environments. With a robust switching capacity of 10 Gbps, 5 Gbps non-blocking throughput, and a forwarding rate of 7 million packets per second, the USW-Flex ensures smooth, high-performance network operations. It supports up to 1,000 VLANs and maintains a MAC address table of 2,000 entries for scalable network segmentation. Layer 2 features such as egress rate limiting, flow control, port isolation, port mirroring, and jumbo frame support provide advanced traffic management and diagnostics. Designed to withstand harsh conditions, the switch operates reliably at ambient temperatures ranging from -40 to 65 C depending on PoE output, and 5 to 95% noncondensing humidity, complemented by ESD protection up to 16kV. This resilient device balances powerful functionality with a compact, lightweight design at only 230 grams (8.1 ounces), delivering efficient performance and versatile deployment options in demanding environments.
